YASKAWA SGM-02A3YB11 AC SERVO MOTOR Sigma-I SERIES

Product Parameters

Model: SGM-02A3YB11

Series: Sigma-I SGM

Rated Power: 200W (0.27 HP,)

Power Supply Voltage: Single-phase AC 200V (200-230V, 50/60 Hz,)

Rated Speed: 3000 r/min

Maximum Speed: 5000 r/min

Rated Torque: 0.637 Nm

Peak Torque: ~1.911 Nm

Rated Current: 2.0 A

Encoder: 13-bit incremental encoder

Shaft End Design: Straight with keyway

Brake: 24V DC holding brake

Oil Seal: No oil/dust seal

Protection Rating: IP55

Insulation Class: B (heat resistance,)

Insulation Resistance: >10 MΩ at DC 500V

Withstand Voltage: AC 1500V, 1 minute

Ambient Temperature: 0°C to +40°C

Ambient Humidity: 20% to 80%

Mounting Method: Flange-mounted

Rotation Direction: Clockwise (CCW) from load side

Vibration Class: V15 (vibration resistance 49 m/s²)

Standards Compliance: CE, UL/cUL

Functions

Low-Inertia Design: Enables rapid acceleration and short settling times, ideal for high-speed, dynamic tasks .

High-Precision Feedback: 13-bit incremental encoder (2048 x 4 ppr, assumed) ensures accurate position control .

Brake Functionality: 24V DC holding brake secures the load during power-off or emergency stops, enhancing safety.

Compact Size: ~60x60 mm flange fits space-constrained applications, simplifying integration.

Durability: IP55 rating (excluding shaft), 49 m/s² vibration resistance, and Class B insulation suit industrial environments.

Compatibility: Pairs with YASKAWA Sigma-I/II drives (e.g., SGDA-02AS, SGDS-02A01A) for speed, torque, and position control.

Low Maintenance: Brushless design reduces maintenance costs and extends lifespan.

Application Scenarios

Chip Mounters: High-speed, precise positioning for semiconductor assembly.

PCB Drilling Machines: Rapid response for accurate drilling tasks.

Small Robotics: Drives compact robot arms or grippers, with brake ensuring safety.

Packaging Machinery: Powers small labeling, sorting, or sealing mechanisms.

Conveyors: Enables precise material handling in compact automation lines.

Industries: Electronics manufacturing, semiconductors, robotics, packaging, light industry.
