YASKAWA SGDV-120A01A002000 HIGH PERFORMANCE SERVOPACK SIGMA-5 SERIES

Product parameter

Model: SGDV-120A01A002000

Series: Sigma-5 SGDV

Rated output power: 1.5kW

Power supply voltage: three-phase 200-230 VAC (nominal 200 VAC, +10%/-15%), 50/60 Hz

Continuous output current: 11.6A (three-phase)

Peak output current: 28 A (three-phase)

Control mode: Rotary servo motor, support analog voltage/pulse train control

Frequency response: 1000 Hz

Encoder feedback: Supported

Communication interface: RS-422 (Support MECHATROLINK-II and other protocols, depending on the configuration of Profibus, DeviceNet)

Analog inputs: 2

Analog output: 2

Number input: 7

Digital output: 3

Ambient temperature: 0 to +55°C

Protection Class: IP1X (suitable for clean, controlled industrial environment)

Cooling method: natural cooling

Certification: UL, EN50178, EN55011, EN61800-3, EN61800-5-1

RoHS: Does not comply with RoHS standards

Feature

High precision motion control: Support position, speed and torque control for a variety of complex motion tasks. Provide 1:500 speed control range, dynamic response is fast.

Advanced control algorithm: It adopts sine wave drive and IGBT pulse width modulation (PWM) control to reduce motor vibration and noise. Built-in vibration suppression to improve load stability.

Easy debugging: No need to adjust the automatic Tuning function (tuning-less), greatly reduce the setup time. Support JOG operation, origin search and full closed loop control.

Communication and integration: Support RS-422 communication, optional MECHATROLINK-II, EtherCAT, RS-232C, RS-485 and other protocols, easy to integrate with the upper controller. Compatible with a wide range of servo motors (Yaskawa and other brands, see compatibility list).

Safety and Reliability: Built-in overload, overvoltage, overcurrent protection function to ensure safe operation. Equipped with alarm history for easy fault diagnosis.

Other features: Support soft boot time setting (0-10 seconds). A/B/C phase line drive output for easy encoder signal processing. Positioning function for high-precision applications.

Application scenario

Robotics: Used for joint drive of industrial robots, providing high precision positioning and fast response. Numerical Control Machine tools (CNC) : Servo motors drive CNC machining equipment to achieve high precision cutting and machining.

Packaging equipment: Control the moving parts in the packaging machine to ensure a fast and accurate packaging process. Semiconductor manufacturing: Used in chip mounting machines, PCB drilling stations and other equipment, to meet the micron level accuracy requirements.

Material handling: Used for automated conveyor lines, AGVs (automated guided vehicles), etc., to optimize logistics efficiency. Food processing equipment: Drive cutting, filling and other equipment in the food production line to ensure hygiene and efficiency.

Printing machinery: Provides stable speed and position control, suitable for high-speed printing equipment.
