YASKAWA SGDV-R70A01A AC SERVO DRIVER Sigma-5 SERIES

Product parameters

Output power: 50W

Input power supply:

Single-phase or three-phase: 200-230VAC, 50/60Hz

Input current: 0.8A (single-phase) / 0.66A (three-phase)

Output current:

Continuous output: 0.66A (three-phase)

Maximum output: 2.1A

Output frequency: 0-500Hz

Control mode: Analog voltage/pulse sequence control, supporting torque, position and speed control

Encoder feedback: Supports high-resolution incremental encoders (such as 20-bit, compatible with SGMAV-A5ADA61)

Communication interface: RS-422

Ambient temperature: 0 to +55°C

Protection grade: IP10

Frequency response: 1kHz (minimum)

Safety certification: UL 508C, EN 50178, EN 61800-3, EN 61800-5-1, IEC 61508 SIL2

Compatibility: SGDV-R70A01A is fully matched with SGMAV-A5ADA61 (50W, 200VAC), with consistent power and voltage, and supports high-precision control.

Function

High-precision control: Supports torque, speed and position control, and achieves sub-micron positioning accuracy in combination with 20-bit encoders (such as SGMAV-A5ADA61).

Advanced tuning No Tuning function (Tuning-less), ready to use out of the box, reducing debugging time. Advanced automatic tuning, adapting to inertia variations up to 30:1.

Vibration suppression: Enhanced vibration suppression function reduces mechanical resonance and ensures smooth operation.

Fast response: 1kHz frequency response shortens positioning time and enhances production efficiency.

Multi-functional output: Supports various digital outputs (such as positioning completion, consistent speed, alarm, etc.) and encoder pulse output (A/B/C phases).

Safety and reliability: Built-in overcurrent and overvoltage protection, compliant with SIL2 safety standards, suitable for harsh industrial environments.

Usability: It provides setup wizards and wiring confirmation functions through SigmaWin+ engineering tools, simplifying installation and debugging.

The collaborative function with SGMAV-A5ADA61: The low-inertia design of the driver and motor combined provides rapid acceleration and deceleration as well as high dynamic response, making it particularly suitable for high-frequency start-stop tasks.

Application scenarios

Semiconductor manufacturing: Wafer handling and chip mounting require high-precision positioning.

Small robots: such as desktop robotic arms and AGV navigation, require compact design and high dynamic response.

Electronic equipment manufacturing: PCB drilling and surface mount technology (SMT) machines require rapid and precise movement.

Packaging equipment: Small packaging machines, label application, which requires stability and high efficiency.

Medical equipment: such as precision testing instruments, requires low vibration and high reliability.

Small CNC equipment: engraving machines, micro CNC machines, which require high response speed.
