YASKAWA SGDV-5R5A01A00200 SERVO MOTOR Sigma-5 SERIES

Product parameters

Model: SGDV-5R5A01A00200

Series: Sigma-5 SGDV

Rated power: 750W

Input power supply:

Voltage: Three-phase 200-230 VAC

Frequency: 50/60 Hz

Current: Approximately 4.7 A

Output power supply:

Voltage: 0-230 VAC, three-phase

Continuous current: 5.5A

Frequency: 0-300 Hz

Control mode: Speed, torque, position control

Control mode: Full-wave rectification, IGBT PWM control, sine wave drive

Speed control range: 1:5000

Encoder support: 20-bit serial encoder

Communication interface: RS-422

Digital input/output

Input: 8 numeric inputs (P-OT, N-OT, /P-CL, /N-CL, /SI0-/SI6, /HWBB1, /HWBB2)

Output: 12 digital outputs (ALO1-ALO3, /COIN, /V-CMP, /TGON, /S-RDY, /CLT, /VLT, /BK, /WARN, /NEAR, EDM1, PAO/PBO/PCO)

Analog input: Torque control: 1 x -3... +3Vdc (adjustable -1...) +1Vdc to -10... +10Vdc, 16μs Speed control: 1 x -6... +6Vdc (adjustable -2...) +2Vdc to -10... +10Vdc, 30μs

Integrated features: Tuning-less Advanced autotuning Vibration suppression JOG operation Origin search Full closed-loop control Alarm history record

Protection functions: overcurrent, overvoltage, undervoltage, overheat and overload protection

Ambient temperature: 0°C to +55°C

Protection grade: IP10

Cooling method: Natural cooling

Special features: Standard conformal coating to enhance corrosion resistance

Feature

High-frequency response: With a minimum response frequency of 1 kHz, it shortens positioning time and enhances dynamic performance.

No tuning function: No manual adjustment required, simplified debugging, and adaptable to various loads.

Advanced automatic tuning: Real-time adaptive load control, optimized performance, and reduced vibration.

Vibration suppression: Enhanced vibration suppression function to ensure smooth movement, suitable for high-precision applications.

Full closed-loop control: Supports external encoder feedback to enhance positioning accuracy.

Flexible communication: RS-422 interface, supporting MECHATROLINK-II, achieving multi-axis synchronization.

Protection function: Built-in overcurrent, overvoltage and overheating protection, with alarm history record to ensure safe operation.

User-friendly: SigmaWin+ Engineering tools offer setup wizards and wiring confirmations, simplifying installation.

Conformal coating: Enhances corrosion resistance and is suitable for harsh environments.

Application scenarios

CNC machine tools: Drive the feed axes of CNC woodworking or metalworking equipment to improve processing accuracy.

Robot: Drive small and medium-sized robot arms to achieve precise trajectory and positioning.

Semiconductor equipment: High-precision tasks for chip mounting or testing equipment.

Packaging machinery: Drive conveyor belts, labeling or sealing equipment to optimize production efficiency.

Material handling: Achieving the handling and positioning of workpieces in an automated production line.

Industry: Electronic manufacturing, woodworking, automotive parts, packaging, semiconductors.
