YASKAWA SGDV-330A15A SERVO DRIVER SIGMA-5 SERIES

Product parameters

Model: SGDV-330A15A

Series: Sigma-5 SGDV

Rated power: 5.0 kW (6.7 HP)

Input power supply:

Voltage: 170-253 VAC, three-phase (nominal 200V, +10%/-15%;) Support 200/208/220/230/240 VAC

Frequency: 50/60 Hz

Current: 28.9A

Output power supply:

Voltage: 0-230 VAC, three-phase

Continuous current: 32.9A

Frequency: 0-300 Hz

Control mode: Speed, torque, position control

Control mode: Full-wave rectification, IGBT PWM control, sine wave drive

Speed control range: 1:5000

Encoder support: 13-bit incremental encoder (2048 x 4) or 24-bit absolute encoder (battery required, such as JZSP-BA01)

Communication interface: RS-422 (Supports MECHATROLINK-II/III; EtherCAT requires additional modules)

Digital input/output Input: 7 x Universal input (/SI0 to /SI6), forward/reverse prohibition (P-OT/N-OT), forward/reverse torque limit (/P-CL/N-CL), base block (/HWBB1, /HWBB2) Output: Alarm (ALM+, ALM-), Positioning completion (/COIN), speed consistency (/V-CMP), motor rotation detection (/TGON), servo readiness (/S-RDY), Torque limit (/CLT), speed limit (/VLT), braking interlock (/BK), Warning (/WARN), Approach (/NEAR), status Monitoring (EDM1), encoder pulses (PAO, PBO, PCO)

Analog input: Torque control: -3... +3Vdc (adjustable -1...) +1Vdc to -10... +10Vdc, 16μs often Speed control: -6... +6Vdc (adjustable -2...) +2Vdc to -10... +10Vdc, often at 30μs

Integrated features: Built-in positioning function Vibration suppression Real-time automatic tuning JOG operation Origin search Full closed-loop control Alarm history record

Ambient temperature: 0°C to +55°C

Protection grade: IP10 (Needs to be installed in the control cabinet to avoid moisture, corrosive gases and dust)

Cooling method: Natural cooling

Feature

High-frequency response: 1.6kHz frequency response, shortening positioning time and enhancing dynamic performance.

Advanced tuning: Real-time automatic tuning and vibration suppression functions simplify debugging and adapt to various load conditions.

Precise control: Speed control range 1:5000, supporting speed, torque and position control, providing smooth and high-precision motion.

Flexible communication: RS-422 interface, supporting MECHATROLINK-II/III or EtherCAT (module required), achieving multi-axis synchronization.

Protection function: Built-in overcurrent, overvoltage, overheating and undervoltage protection, with alarm history record to ensure safe operation.

Quick setup: SigmaWin+ Engineering tools offer setup wizards and wiring confirmation functions, reducing debugging time.

Compatibility: In conjunction with YASKAWA Sigma-5 series rotary motors (such as SGMGV-55A), it supports incremental or absolute encoder feedback and requires battery support for absolute encoding.

Application scenario

Robot: Drives large robot arms to achieve high-precision trajectory and positioning.

CNC machine tools: Control the feed axis or spindle of CNC machine tools to improve processing accuracy.

Packaging machinery: Drives high-speed conveyor belts, labeling or sealing equipment to enhance production efficiency.

Material handling: Achieving the handling and positioning of heavy workpieces in automated production lines.

Semiconductor equipment: High-precision tasks for wafer handling or testing equipment.

Industry: Robotics, electronic manufacturing, automotive parts, packaging, semiconductors, food processing.

Advantage Products:
