FESTO DSR-25-180-P PNEUMATIC SEMI-ROTARY ACTUATOR

Product parameter

Model: DSR-25-180-P

Size: 25

Rotation Angle: 180° (adjustable range 0°-180°)

Buffer Angle: 1.8°

Working pressure: 1.5 bar to 8 bar (Max. 9 bar / 116 psi)

Theoretical torque: 5 Nm (at 0.6 MPa / 6 bar)

Maximum rotation frequency: 3 Hz (at 0.6 MPa / 6 bar)

Pneumatic connection: M5 threaded port

Working medium: Compressed air, according to ISO 8573-1:2010 [7:-:-]

Operation mode: Double-acting

cushioning mode: Elastic cushioning rings/plates at both ends

Location detection: None

Drive shaft material: steel, nickel plated

Sealing material: NBR (Nitrile butadiene rubber)

Compliance standards: VDMA24364-B2-L, LABS (PWIS) compliance

Installation mode: Through hole. Installation position is optional

Feature

High precision rotation: Provides 180° adjustable rotation Angle for precise twisting or positioning tasks.

Dual action design: Driven by compressed air, ensures fast response and high efficiency.

Elastic buffer: both ends are equipped with elastic cushion to effectively absorb impact and extend service life.

Flexible installation: Support through hole installation, installation position is optional, adapt to a variety of mechanical structures.

Durable material: nickel-plated steel drive shaft and NBR seals are corrosion resistant and suitable for industrial environments.

Position-free detection: Simplified design for scenarios without complex feedback.

Application scenario

Part handling and transfer: For the rotation, flipping or positioning of parts in automated production lines.

Valve control: Drive valve switch, widely used in fluid control systems (such as water treatment, chemical).

Assembly line: The rotation or Angle adjustment of the workpiece is realized during assembly.

Packaging machinery: used for parts that need to rotate in packaging equipment (such as sealing and labeling).

Robot end effector: As a rotating part of the robot arm, it provides twisting function.

Other industrial applications: such as semiconductor manufacturing, rotation control of solar devices, MEMS and photonics devices.

Typical industries: Manufacturing, automotive industry, electronic assembly, food and beverage processing, pharmaceutical, etc.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
