FESTO DSR-16-180-P PNEUMATIC SEMI-ROTARY DRIVE DSR SERIES
The FESTO DSR-16-180-P is a compact pneumatic Semi-rotary Drive with a rotary vane design that provides a 180° rotation Angle for double-acting operation.
HS CODE : 8538909200
Product No :
FESTO DSR-16-180-PManufacture :
FESTOSize (cm) :
3*4*6Weight (kg) :
0.2Origin :
CHINAWarranty :
12 MonthLead Time :
Ready DRIVEDescription :
PNEUMATIC SEMI-ROTARY DRIVEProduct parameter
Model: DSR-16-180-P
Part number: 11909
Size: 16
Bore: 16 mm
Rotation Angle: 180° (adjustable range 0°-180°)
Buffer Angle: 2.2°
Working pressure: 2 bar to 8 bar
Theoretical torque: 1.25Nm (6 bar)
Maximum rotation frequency: 3 Hz (6 bar)
Pneumatic connection: M5 threaded port
Working medium: Compressed air, according to ISO 8573-1:2010
Operation mode: Double action
Buffer mode: elastic buffer ring/plate at both ends
Location detection: None
shaft type: Spigot shaft (positioning shaft)
Materials:
Drive shaft: steel, nickel-plated
Seal: NBR (Nitrile rubber)
Compliance standards: VDMA24364-B2-L, LABS (PWIS) compliance
Installation mode: Through hole. Installation position is optional
Ambient temperature: -10°C to +60°C
Feature
Precise rotation: 180° adjustable Angle for light positioning and twisting tasks.
Low torque output: 1.25Nm theoretical torque for small loads.
Dual action drive: Fast response, efficient operation.
Elastic cushioning: cushioning at both ends reduces impact and extends life.
Compact design: Small size for space-constrained applications.
Flexible installation: Through hole design, support any installation position.
Durable material: nickel-plated steel shaft and NBR seal for corrosion resistance.
Application scenario
Small parts handling: Rotation or positioning of light parts in an automated production line.
Valve control: Small fluid control systems (e.g. laboratory equipment, light industry).
Electronic assembly: Angle adjustment of miniature workpieces.
Packaging machinery: Rotary action of lightweight sealing or labeling equipment.
Robotic end effector: Twisting function of a small robotic arm.
Industries: Electronics manufacturing, light industry, food processing, medical equipment, laboratory automation.
