FESTO DFM-16-20-P-A-GF A DUAL-ACTING PNEUMATIC GUIDED DRIVE DFM FAMILY

Product parameter

Model: DFM-16-20-P-A-GF

Part Number: 170833

Bore: 16 mm

Stroke: 20 mm

Working pressure: 2 bar to 10 bar

Working mode: Double-acting

guide type: Plain-bearing guide

cushioning mode: Elastic cushioning rings/plates at both ends

Pneumatic connection: M5 threaded port

Maximum speed: 0.8m /s

Working medium: Compressed air, according to ISO 8573-1:2010 [7:4:4], lubricating oil can be used

Position detection: Built-in magnet, Proximity sensor support

Theoretical force:

Propulsion force: 120 N (6 bar)

Return force: 101 N (6 bar)

Materials:

Shell: Wrought Aluminium alloy

Dynamic seal: Polyurethane (Polyurethane)

Static seal: Nitrile butadiene rubber (NBR)

Guide rod/piston rod: High-alloy stainless steel

Ambient temperature: -20°C to +80°C

Compliance standards: RoHS, partially VDMA24364-B2-L

Feature

High load capacity: The sliding guide design provides high torsional and lateral force resistance and is suitable for handling high loads (approximately 100% higher than comparable products).

Dual action drive: Supports thrust and return action for improved accuracy and speed.

Elastic buffer: Elastic buffer at both ends reduces impact and noise and extends service life.

Position detection: Built-in magnets support proximity sensors for easy motion monitoring and control.

Flexible installation: A variety of installation and air port options are available to suit different application requirements.

Durable material: Aluminum alloy housing and stainless steel guide rod/piston rod, wear and corrosion resistance, suitable for harsh environments.

Compact design: Integrated driver and guide rail, saving space and suitable for small installation scenarios.

Application scenario

Industrial assembly lines: used for positioning, clamping or handling of parts, especially in the assembly of electronic and automotive parts.

Packaging machinery: Performs precise linear push-pull operations in packaging equipment, such as sealing or labeling.

Food and beverage processing: Durable materials and compact design for a clean environment in food processing lines.

Medical equipment: Components such as medical imaging equipment that require smooth linear motion.

Material handling: Moving heavy objects or adjusting workpiece positions in an automated production line.

Other applications: linear drives in semiconductor manufacturing, solar equipment or small robotic systems.

Typical industries: manufacturing, automobile industry, electronics, food processing, medical, etc.
