BENTLY NEVADA 330104-00-08-11-01-05 3300 XL FAMILY 8MM PROXIMITY PROBE

Technical parameter

Size: No thread length 0mm, total shell length 80mm, total system length 0.5m.

Probe and cable: Miniature coaxial Click Loc™ connector and Fluid Loc cable with connector protection.

Other parameters: Sensitivity may be 7.87V/mm (200mV/mil)± 5%, linear range 2mm, frequency response 0-10kHz, supply voltage -17.5Vdc to -26Vdc, current maximum 12mA.

Feature

Accurate displacement measurement: It can accurately measure the small distance change between the measured object and the probe, which is often used to monitor the displacement of the rotating shaft, determine whether the equipment components are in the normal working position, and provide data basis for equipment installation, debugging and maintenance.

Vibration monitoring and analysis: It can capture the vibration information of the measured object in real time, including amplitude, frequency and other parameters, and evaluate the vibration state of the equipment by analyzing these data, and timely find abnormal vibration caused by unbalance, misalignment, loosening and other faults.

Speed and key phase measurement: In conjunction with the relevant system, the key phase of the rotating machinery can be determined to provide a phase reference for analyzing the operating condition of the equipment, and can also be used to measure the rotational speed of the rotating machinery to monitor whether the equipment is running normally.

Application Scenario

Power industry: Suitable for turbine, generator, fan, water pump and other equipment shaft vibration, shaft displacement, key phase and speed monitoring, help to timely detect the potential trouble of equipment, ensure the safe and efficient operation of power generation equipment.

Petrochemical industry: can be used in the oil refinery compressor, pump, mixer and other equipment vibration and displacement monitoring, to ensure the normal operation of equipment in harsh environment, to prevent vibration or displacement caused by leakage, failure and other problems.

Metallurgical industry: In steel production, the shaft vibration and displacement of large mechanical equipment such as blast furnace, converter and continuous casting machine can be measured to optimize the operating parameters of equipment, improve production efficiency and reduce the number of equipment maintenance.

Other industrial fields: It can also be used for rotary machinery in paper making, cement, mining and other industries to provide guarantee for equipment operation and maintenance, and can also be used as a high-precision measurement tool in rotor dynamics research and mechanical structure vibration analysis experiments in scientific research institutions.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
