OMRON R88M-K10030T-S2 AC SERVO MOTOR G5 SERIES

Product parameter

Power: 100 W

Rated voltage: 200 VAC (single or three phase, depending on driver)

Rated speed: 3000 RPM (RPM)

Rated torque: 0.32Nm

Maximum instantaneous torque: about 0.95Nm

Encoder type: Absolute encoder (20-bit resolution)

Shaft type: Straight shaft with keyway (S2)

Protection Class: IP67 (except shaft openings)

Operating environment:

Operating temperature: 0°C to 40°C

Storage temperature: -20°C to 65°C

Humidity: 20% to 85% (no condensation)

Feature

Absolute encoder: Support position memory after power failure, no need to return to the origin each time power on, improve efficiency.

High precision control: 20-bit encoder resolution ensures superior position and speed control.

Compact design: Small size and high power density for space-constrained applications.

High dynamic response: Fast acceleration and deceleration, response frequency up to 2 kHz (depending on the driver).

Durability: IP67 protection grade, suitable for wet or dusty industrial environments.

Application scenario

Small automation equipment: such as conveyor belts, sorters, for precise light load motion control.

Packaging machinery: Fast positioning in a labeling machine or sealer.

Electronic manufacturing: For the precision movement of semiconductor equipment or chip mounters.

Test equipment: Used in laboratory installations requiring stable rotating outputs.

Robotics: Suitable for the drive of small robotic joints or end effectors.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
