OMRON R88D-WT10H SERVO DRIVER OMNUC W FAMILY

Product parameter

Model: R88D-WT10H

Rated power: 1kW

Input voltage: single-phase/three-phase 200-230V AC (170-253V), 50/60Hz

Control mode: full digital servo control

Communication interface: MECHATROLINK-II (High Speed Motion Control Bus)

Output current: Continuous output current 7.6A (rms)

Instantaneous maximum output current: about 17.0A (rms)

Speed feedback: Support for incremental or absolute encoders (depending on matching motor)

Inverter method: PWM (Pulse Width modulation) based on IGBT

PWM frequency: 11.7kHz

Operating temperature: 0°C to 55°C

Storage temperature: -20°C to 65°C

Max working humidity: 90% (no condensation)

Protection Class: IP10 (built-in panel design)

Certification standards: Compliant with UL, cUL and EN (EMC and Low Voltage Directives)

Feature

MECHATROLINK-II communication: Supports high-speed communication (up to 10 Mbps) for multi-axis synchronous control and real-time data exchange.

High precision positioning: Positioning accuracy is ensured through optimized control algorithms and encoder feedback.

Multiple control modes: Position, speed and torque control for different applications.

Automatic tuning: Built-in automatic tuning function simplifies parameter setting and ADAPTS to load changes.

Overload protection: overload, overvoltage, overheating and other protection functions to ensure equipment safety.

Status monitoring: The LED indicator on the front panel displays the operating status and fault information.

Compatibility: Seamless matching with Omron W Series servo motors such as R88M-W1K030H.

Application scenario

Packaging machinery: used to control the precise positioning of high-speed conveyor belts or packaging mechanisms.

Processing equipment: such as CNC machine tools, laser cutting machine movement shaft drive, to provide high responsiveness.

Automated production lines: Precise control in parts handling or assembly.

Printing equipment: Control the movement of the printing roller or paper feeding mechanism to ensure consistency.

Robotics: As a drive unit for medium-sized robot joints or actuators.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
