OMRON R7M-AP10030 AC SERVO DRIVER SMARTSTEP A FAMILY

Product parameter

Model: R7M-AP10030

Rated power: 100W

Rated voltage: 200-240V AC

Rated speed: 3000 rpm

Maximum speed: 4500 rpm (subject to driver support)

Rated torque: 0.318 Nm

Peak torque: 0.95Nm

Encoder type: Incremental encoder, 2000 pulse/revolution

Rotor inertia: about 0.026 × 10⁻⁴ kg·m²

Current: Rated current 0.87A, maximum current 2.6A

Protection Class: IP55 (except shaft penetration)

Operating temperature: 0°C to 40°C

Storage temperature: -20°C to 60°C

Max working humidity: 85% (no condensation)

Certification standards: UL, cUL and EN (IEC 60034-1/-5)

Feature

High precision positioning: An incremental encoder (2000 pulses/RPM) provides reliable position feedback.

High dynamic response: Support fast acceleration and deceleration, suitable for high-frequency motion control.

Flat design: Compact flat construction for space-constrained applications.

Durability: IP55 protection, suitable for dust and light splashing in industrial environments.

Compatibility: Seamless match with Omron SmartStep series servo drives such as R7D-AP01H.

Straight axis design: easy to connect directly with mechanical loads.

Application scenario

Small packaging equipment: used to drive the precise positioning of conveyor belts or packaging mechanisms.

Electronic Assembly: Provides stable, precise motion control in the assembly of precision electronic components.

Light machinery: such as positioning drives in small cutting machines or printing equipment.

Test equipment: Used in laboratory or production line test tooling for high responsiveness.

Automated fixtures: Precise movement in small fixtures or handling devices.
