OMRON R7D-APA3L A SERVO DRIVER SMARTSTEP A SERIES

Product parameter

Model: R7D-APA3L

Rated power: 30W

Input voltage: single-phase 100-115V AC (85-127V), 50/60Hz

Control mode: full digital servo control

Input type: pulse input

Output current: Continuous output current 0.42A (rms)

Speed feedback: Incremental encoder, 2000 pulses/RPM

Inverter method: PWM (Pulse Width modulation) based on IGBT

PWM frequency: 11.7kHz

Operating temperature: 0°C to 55°C

Storage temperature: -20°C to 85°C

Max working humidity: 90% (no condensation)

Protection Class: IP10 (built-in panel design)

Certification standards: Compliant with UL, cUL and EN (EMC and Low Voltage Directives)

Feature

Pulse input control: High-speed pulse input (up to 500 kpps) is supported for precise position control.

Automatic tuning: Built-in automatic tuning function, simplify parameter setting, adapt to different load conditions.

High responsiveness: Provides fast acceleration and deceleration response, suitable for dynamic positioning tasks.

Overload protection: with overload, overvoltage, overheating and other protection functions to ensure safe operation of the equipment.

Simple operation: Without complex programming, it can be controlled by sending pulse signals from an external controller.

Compatibility: Seamless matching with Omron SmartStep A series servo motors such as R7M-A03030.

Status indicator: The LED indicator on the front panel displays the operating status and fault information for easy debugging and maintenance.

Application scenario

Small packaging equipment: used to control the positioning of small conveyor belts or packaging materials.

Electronic Assembly: Provides stable, precise motion control in the assembly of precision electronic components.

Light machinery: such as positioning drives in small cutting machines or printing equipment.

Test equipment: Used in laboratory or production line test tooling for high responsiveness.

Low-voltage environment automation: Suitable for small automation systems in Japan or other regions where 100V AC power is used.
