OMRON R7D-AP02H A SERVO DRIVER SMARTSTEP A FAMILY

Product parameter

Model: R7D-AP02H

Power supply voltage: single-phase 200-230V AC, 50/60 Hz

Rated output power: 200W

Rated current: 1.65A

Load voltage: 200V

Inductance: 20.0mH

Regenerative energy absorption capacity: 37.1J

Control mode: pulse train input position control

Compatible motor: Compatible with Omron SmartStep series servo motors (e.g. R88M series)

Feature

Simple setup and operation:

Setup via switches on the front panel without complicated parameter programming.

Support real-time automatic tuning function, simplify the debugging process.

High performance motion control:

Provides high torque output at high RPM for fast positioning.

Support dynamic braking function, can be customized according to the requirements of the braking characteristics.

Energy Management:

With a regenerative energy absorption capacity of 37.1J, effectively manage the excess energy generated by the motor and reduce heat loss.

User friendliness:

Equipped with error code display for easy fault diagnosis.

Support USB port, easy parameter adjustment and monitoring.

Communication capability:

Supports multiple communication protocols for easy integration into existing automation systems.

Application scenario

Packaging machinery: used for precise control of positioning and speed during packaging.

Material handling: such as conveyor belts, mechanical arms and other equipment that requires smooth movement.

Small processing equipment: such as CNC machine tools, engraving machines and other scenarios requiring high torque and fast response.

Assembly line: Used for positioning and moving parts in automated assembly.

Alternative stepper motor systems: in upgrade projects requiring higher performance but with limited budgets.
