OMRON R7M-A40030-S1-D AC SERVO MOTOR A SERIES

Product parameter

Type: AC servo motor

Rated power: 400 W

Supply voltage: 230 VAC (single phase)

Rated speed: 3000 rpm

Maximum speed: 4500 rpm (depending on driver configuration)

Rated torque: about 1.27Nm

Max torque: approx. 3.82Nm (peak, subject to driver support)

Encoder: Incremental encoder (2500 ppr)

Inertia: Low inertia design

Protection Class: IP67 (except connector part)

Brakes: No brakes (standard configuration based on "D")

Keyway: with key and tapping holes (" S1 "feature)

Operating temperature: 0°C to 40°C

Installation method: Flange installation

Feature

Efficient positioning control

Provides superior performance to stepper motors for simple point-to-point motion tasks.

Fast dynamic response

Low inertia design, support high frequency start and stop and quick adjustment.

Shaft design with key

The "S1" configuration features keyways and percussion holes for easy connection to mechanical components for increased installation flexibility.

Easy to set up and use

Working with the SMARTSTEP driver, you can adjust parameters with a simple switch to reduce debugging difficulty.

High reliability

IP67 protection rating ensures stable operation in dusty or humid environments.

Application scenario

Automated production line

For conveyor or roller systems, providing precise speed and position control with medium power.

Packaging machinery

Fast positioning in labeling machines, sealers or small filling equipment, with key design for easy transmission connection.

Lightweight robot

Joint drive for small and medium-sized robot arms to provide smooth power output.

Printing equipment

Support synchronous operation of paper feed or roller system to ensure consistency of operation.

Simple assembly unit

Replace stepper motors for low-cost, high-efficiency motion control tasks.
