FUJI ELECTRIC GYG152CC2-T2G MEDIUM-INERTISA AC SERVO ALPHA5 SERIES

Product parameter

Rated power: 1500 W (1.5 kW)

Rated voltage: 200 VAC (three-phase, visual amplifier configuration)

Rated current: about 9.0A

Rated torque: 7.16Nm

Maximum torque: approx. 21.48 Nm (peak)

Rated speed: 2000 rpm

Maximum speed: 3000 rpm

Rotor inertia: about 10.2 × 10⁻⁴ kg·m² (medium inertia)

Encoder type: 20-bit incremental encoder (high resolution, about 1,048,576 pulses/turn)

Protection level: IP67 (required to use standard connectors)

Cooling method: natural cooling

Operating temperature: 0°C to 40°C

Storage temperature: -20°C to 60°C

Ambient humidity: 20% to 80% (no condensation)

Shaft configuration: Shaft with keyway, threaded hole (standard)

Feature

High precision positioning: The 20-bit incremental encoder provides a resolution of approximately 1,048,576 pulses/turn for sub-micron positioning accuracy. Suitable for high-precision motion control tasks.

Strong torque output: Medium inertia design (10.2 × 10⁻⁴ kg·m²) ensures stable operation under heavy loads and reduces mechanical vibration. Rated torque 7.16 Nm, peak torque up to 21.48 Nm for high load applications.

Efficient operation: Optimized magnetic circuit design reduces energy consumption and provides stable torque output over a wide speed range. The rated speed is 2000 rpm and the maximum speed is 3000 rpm, suitable for medium-speed and stable operation.

Strong environmental adaptability: IP67 protection rating (need to match connectors), dust and water resistant, suitable for harsh industrial environments. Shaft with oil seal (T2G configuration) prevents oil, dust or contaminants from entering.

Flexible control compatibility: Position, speed and torque control modes are supported and work seamlessly with ALPHA5 amplifiers such as RYC152C3-VVT2. Compatible with Modbus, EtherCAT and other protocols (visual amplifier support).

Easy to integrate: Shafts with keyways and threaded holes facilitate the connection of couplings, pulley or other loads. Moderate size for a variety of installation environments.

No brake (standard) : The standard model has no built-in brake, optimized for dynamic application; The brake version (T2G-B) is suitable for scenarios where the load needs to be maintained.

Application scenario

Industrial Automation:

Robots: Drive heavy-duty robotic arms or clamps that provide smooth movement and high load capacity.

CNC machine tool: Used for spindle or feed shaft to meet the machining needs of high precision and high torque.

Packaging equipment: Drive heavy duty filling machines, sealers or packing machines to ensure efficient operation.

Material Handling:

Conveyor belt: Controls the heavy transfer system for smooth, reliable material transfer.

Automated Guided Vehicle (AGV) : Provides powerful motion control for heavy-duty AGVs.

Electronic Manufacturing:

Assembly line: Drive heavy duty mounters or assembly equipment to meet high precision positioning.

Test equipment: Used to automate the inspection of moving parts of the system to ensure stable operation.

Textile machinery: Drive heavy duty looms, knitting machines or cutting equipment for smooth operation under load, and oil seals are designed for lubricant environments.

Medical equipment: Drive large diagnostic equipment (such as MRI or CT scanners) or heavy-duty laboratory platforms for stability and precision.

Special equipment: For laser cutters, industrial printers or heavy-duty test platforms that require high torque and reliable operation.
