AR1220EVW Enterprise-Grade Router

Main specifications:

Device model: AR1220EVW

Interface:

Eight GE (Gigabit Ethernet) electrical interfaces: Support high-speed Ethernet connections, suitable for various network requirements.

2 SFP (small pluggable) optical interfaces: Support fiber connection, suitable for remote and long distance data transmission.

2 E1/T1 ports: For traditional E1/T1 access, suitable for voice and data transmission.

1 AUX interface: for asynchronous serial communication.

2 USB ports: Support local device management, file transfer or maintenance.

One Console port: used for local management and configuration.

Wireless features:

Wireless module: The integrated wireless module supports Wi-Fi access and is suitable for environments requiring wireless network coverage.

Wireless standards: Support common wireless standards, such as 802.11b/g/n/ac, to provide reliable wireless connectivity.

Wireless management: Support wireless network configuration and management, including SSID, encryption, wireless signal strength adjustment.

Performance characteristics:

Forwarding performance: Up to 1 Gbps forwarding capability to meet the high bandwidth requirements of small and medium-sized enterprises.

Processing capability: Equipped with high-performance processor and large memory, support complex network services and multiple concurrent connections.

Routing protocol: Supports dynamic routing protocols such as OSPF, BGP, RIP, and IS-IS, adapting to different network environments.

VPN support: Supports IPSec VPN, SSL VPN, MPLS VPN and other VPN protocols to ensure secure remote access.

Security function: Built-in firewall, NAT, ACL and other security functions to protect network security.

QoS: Supports comprehensive QoS policies to ensure bandwidth and quality of service for critical applications.

Management and maintenance:

Management mode: Supports various management modes, such as Web UI, CLI (command line interface), SNMP, Telnet, and SSH.

Remote management: Huawei iMaster NCE-Campus or other network management tools can be used for centralized management.

High availability: Supports link backup and redundancy to enhance network stability and reliability.

Physical specifications:

Dimensions: 442 mm x 310 mm x 44.5mm (W x D x H)

Weight: About 4.5kg

Power Supply: AC 100V-240V input, support single power supply redundancy design.

Application scenario:

Small and medium-sized enterprises: Suitable for the headquarters or branches of small and medium-sized enterprises, providing stable network connectivity and wireless coverage.

Branch network: Connects to the headquarters through VPN to ensure data transmission security and stability.

Wireless access: Provides wireless network access for offices or public areas that require wireless coverage.

Expansion capability:

Modular design: Supports the expansion of different business modules, such as voice modules, WAN modules, etc., customized according to enterprise requirements.

Future expansion: Support more functions and future network requirements through the addition of modules or software upgrades.

The Huawei AR1220EVW is an enterprise-class router with integrated wireless capabilities, suitable for small and medium-sized enterprises and branches that require wireless network coverage and powerful routing capabilities.
