ALLAN BRADLEY 2094-PRS-8 Kinetix 6000/6200/6500 8-SLOT POWER RAIL

Product parameter

Number of slots: 8 (1 converter slot +7 inverter slots)

Compatible modules: Kinetix 6000/6200/6500 series IAM, AM, shitter module and slot filling module

Input voltage: 230V or 460V AC (depending on the module connected)

Mounting method: DIN rail or panel mounting

Dimensions: Approx. 534 mm (W) x 262 mm (H) x 68 mm (D)

Weight: Approx. 3.2kg (excluding module)

Operating temperature: 0°C to 50°C (32°F to 122°F)

Storage temperature: -40°C to 70°C (-40°F to 158°F)

Relative humidity: 5% to 95% (non-condensing)

Altitude:

1000 m (3281 ft) without derating operation

Derating is required at 3,000 m (9,843 ft)

Vibration range: 5-55Hz, 0.35mm displacement; 55-500 Hz, 2.0g peak acceleration

Impact rating: 15 g, 11 ms half sinusoidal pulse

Protection class: IP20 (need to be installed in the control cabinet)

Feature

Multi-axis support: Support 1 integrated axis module (IAM) and up to 7 axis modules (AM) to achieve 8-axis synchronous control to meet the needs of large multi-axis systems.

Efficient wiring: Integrated power and control signal bus, reduce external wiring complexity and installation time, improve system cleanliness and efficiency.

Flexible configuration: Support a variety of module combinations (such as AM, shunt module or slot filling module), can be flexibly expanded or adjusted according to application requirements.

High reliability: The rugged design ensures stable operation in demanding industrial environments and a long service life.

Modular design: Seamless compatibility with Kinetix series drive modules for easy system upgrades and maintenance.

Application scenario

Automated production lines: Power and signal support for large multi-axis robots, assembly lines and processing equipment to ensure efficient and coordinated operation.

Packaging system: Multi-axis precision control in high-speed sorters, packaging machines and logistics sorting equipment to improve production efficiency.

Material handling: Support modular integration of heavy conveyor belts, stackers and automated storage systems to accommodate complex dynamic load requirements.

Printing and textile: Multi-axis synchronous movement in printing presses and textile equipment to ensure product quality and stability.

Automotive industry: Used in automotive assembly lines and test equipment to provide reliable multi-axis control support.

Advantage Products:

All items are Distributor Ready-stock Genuine Brand-new Supplying, please inform us if the other conditions are needed, Used, Open-box, Refurbished, etc.

Many Available just wait for you, feel free to ask to get better deal!!!
