6ES7155-5AA00-0AB0 Siemens SIMATIC ET 200MP S7-1500 PROFINET IO Interface Module

Basic information:

Product name: Siemens SIMATIC ET 200MP S7-1500 PROFINET IO interface module

Model: 6ES7155-5AA00-0AB0

Series: SIMATIC ET 200MP

Type: PROFINET I/O interface module

Adaptive system: Compatible with S7-1500 PLC system

Communication protocol: PROFINET

Main features:

PROFINET Communication support: Based on PROFINET IO protocol, the module provides high-speed and reliable communication connection for ET 200MP system and supports fast data exchange with S7-1500 PLC. The use of industry standard PROFINET protocol for communication can achieve high-speed data transmission and adapt to the high requirements of data processing speed and accuracy in the industrial environment.

High-performance I/O interface: The interface module can connect the ET 200MP I/O module to the S7-1500 PLC system, and supports various types of I/O data exchange, such as digital input and output, analog input and output, temperature sensor input, etc. It supports distributed I/O configuration and can flexibly expand I/O points according to application requirements, which is suitable for large-scale automation systems.

Up to 1Gbps data transmission rate: The module supports high-speed PROFINET communication, and the data transmission rate can reach 1Gbps, ensuring low latency and stable communication performance in applications with high data volume. High-speed communication ensures real-time data processing in automated systems, especially for industrial applications that require fast response times.

Flexible I/O expansion: The module has a modular design that can flexibly expand the I/O module of the ET 200MP series to provide more input and output points to meet the needs of industrial automation systems of different sizes.

When used in conjunction with other ET 200MP modules, it is possible to create a distributed and flexible I/O network architecture in the S7-1500 PLC system.

Diagnostic function and remote monitoring: Built-in LED indicator can display the working status of the device, including connection status, data transmission status, etc., to help users monitor the operating status of the device in real time. PROFINET remote diagnosis function is supported, and the module fault information and diagnosis information can be fed back to the central control system through the network, which is convenient for troubleshooting and maintenance.

Reliability and durability: IP20 protection grade, suitable for industrial control cabinet installation, can effectively prevent dust and other objects from entering, adapt to a variety of industrial environments.

The module supports an industrial-grade temperature range (typically 0°C to +60°C) and can operate stably in both high and low temperature environments.

Technical specifications:

Communication protocol: PROFINET IO

Communication rate: up to 1Gbps

Input voltage: 24V DC

Mounting method: DIN rail mounting

I/O interface: Suitable for the ET 200MP series I/O module

Protection level: IP20

Operating temperature range: 0°C to +60°C

Diagnostic function: Remote diagnosis and status monitoring via PROFINET

Application scenario:

Distributed I/O configuration: In an automated production line, the 6ES7155-5AA00-0AB0 can be used to connect the ET 200MP I/O module to the S7-1500 PLC system at high speed to facilitate the management of multiple remote I/O nodes for distributed control.

Complex automation control system: Suitable for complex industrial automation control systems, capable of connecting a large number of input and output devices through PROFINET, and centralized control and monitoring through S7-1500 PLC.

Remote I/O expansion and monitoring: For remote monitoring and data acquisition scenarios requiring multiple I/O modules, the 6ES7155-5AA00-0AB0 provides efficient data exchange channels and remote diagnosis functions, reducing the difficulty of system cabling and facilitating device management.

High-speed data acquisition and real-time monitoring: suitable for applications requiring high frequency and high-speed data acquisition, such as production line monitoring, material tracking, equipment status monitoring, etc.
