6AV6647-0AH11-3AX0 Siemens KP300 BASIC MONO PN 3.6 Inch HMI

6AV6647-0AH11-3AX0 Details

Model and series

Model: 6AV6647-0AH11-3AX0

Series: SIMATIC HMI

Type: KP300 BASIC MONO PN 3.6 Inch HMI (3.6 inch Monochrome HMI)

Function and use

Simplified operating interface: This HMI device helps operators quickly understand equipment status, warnings, and production information by providing concise graphical and text displays. It applies to scenarios that require simple display and operation.

Monitoring and control function: It can be integrated with an automated control system (such as PLC) to display the real-time status of the device, input/output data, and provide a basic operating interface to control the machine or equipment.

Alarm and diagnosis: Support to display fault information, alarm prompts and system status feedback to help operators identify and deal with problems in a timely manner.

Technical characteristics

3.6-inch display: A black and white display is used to display basic information, such as status indication, data collection, and simple control.

Monochrome display: Although monochrome, the display has a clear contrast ratio, ensuring good readability in industrial environments, especially in high light or harsh environments.

Resolution: Displays are typically 320 x 240 pixels, suitable for text, numbers and simple graphics.

Touch screen: Equipped with resistive touch screen, support simple touch input and control, intuitive operation, rapid response.

Profinet Connectivity: Supports communication with automation systems via the Profinet protocol, ensuring smooth data exchange and control operations between HMI and PLC and other automation control devices.

Simple configuration and operation: KP300 MONO's interface design is simple and easy to configure and deploy, which is suitable for application scenarios where the operation interface is not demanding but still requires efficient control.

Compatibility

Compatible with Siemens PLC: Support for connection with Siemens PLC (such as S7-1200, S7-1500, etc.) via Profinet, providing a simple interface and data exchange capability.

Suitable for simple control tasks: Especially suitable for applications requiring simple display and control functions, such as machine control, transmission systems, etc.

Installation and maintenance

Installation method: KP300 MONO panel can be mounted on a panel or DIN rail, and the installation method is flexible to adapt to a variety of industrial site needs.

Industrial grade design: With a rugged housing, adapt to the industrial environment in temperature difference, vibration and dust and other factors, can be long-term stable operation.

Easy operation and maintenance: The panel is intuitive to operate and easy to maintain, making it easy for operators to get started quickly.

Technical parameter

Display size: 3.6 inches, suitable for monitoring and operation of small devices or compact control systems.

Display type: Monochrome (MONO), suitable for displaying simple text, symbols, alarms and status indicators.

Resolution: 320 x 240 pixels, ensuring clear text and digital information.

Interface: Profinet interface to support high-speed data exchange with Siemens PLC and other equipment.

Operating temperature range: suitable for -20°C to +50°C, ensuring stable operation in a wide range of industrial environments.

Power requirements: 24V DC power supply, suitable for industrial application power supply standard.

Advantages and characteristics

Compact design: The 3.6-inch size makes the HMI ideal for space-constrained devices or control panels, providing efficient monitoring and control in tight Spaces.

Simple display: The monochrome display is suitable for displaying text, status and simple alarm information to meet basic monitoring needs.

Profinet Compatibility: The Profinet connection ensures efficient integration with Siemens PLC and other automation control equipment to improve the communication performance of the system.

Strong durability: Industrial design, adapt to a variety of harsh environment for long-term stable operation, strong anti-interference.

Easy operation and configuration: The simple operation interface and convenient configuration process help operators quickly deploy and use.

Cost effective: As a basic HMI, the KP300 MONO offers a cost-effective solution for applications where interface requirements are low.

Application scenario

Simple equipment control: suitable for equipment control that does not require complex operating interfaces, such as small production lines, mechanical equipment, conveying systems, etc.

Production line monitoring: In the production process to monitor the running status of machinery and equipment, production parameters and real-time data, timely find and deal with problems.

Automation control system: provides human-machine interaction interface for simple control tasks in automation system, such as conveyor belt control, stand-alone equipment monitoring, etc.

Energy Management and Monitoring: In the energy consumption monitoring system, provide real-time data presentation and fault diagnosis functions to help optimize energy use.
