6AV3688-3EH47-0AX0 Siemens SIMATIC HMI KP32F PN Key Panel

6AV3688-3EH47-0AX0 Details

Model and series

Model: 6AV3688-3EH47-0AX0

Series: SIMATIC HMI

Type: KP32F PN Key Panel (32 key panel)

Function and use

Mechanical key input: Equipped with 32 function keys for human-machine interaction in industrial automation control systems, the panel provides mechanical key input for industrial applications requiring high reliability.

Integration with PLC: KP32F panel can be directly integrated with Siemens PLC (such as S7-1200, S7-1500), through a dedicated communication protocol and automatic control system for data exchange, simplify the operation interface.

Data input and control: Users can enter data and issue operation commands to production equipment or control systems through the panel, supporting daily operation control in industrial environments.

Technical characteristics

32 function keys: Equipped with 32 function keys, suitable for various control functions and operation command input, you can customize the keyboard functions according to actual requirements.

Industrial grade design: Rugged design to adapt to the harsh working environment of industrial sites. It has good anti-interference, vibration resistance and high temperature resistance to ensure long-term stable work.

High reliability and durability: The mechanical keys are specially designed for a long service life and are suitable for high frequency operating environments. The feedback of the key is clear, and the user can perceive a clear response when operating.

Haptic feedback: With mechanical haptic feedback, users can get accurate confirmation when entering, suitable for industrial environments requiring high-precision operation.

Integrated communication interface: Communication with the control system through the Profinet (PN) interface supports fast and stable data transmission, facilitating seamless integration with the Siemens control system.

Compatibility

Compatible with Siemens PLC: The panel is compatible with Siemens' S7 series PLC, S7-1200, S7-1500 and other SIMATIC automation systems to support data interaction and control instruction transfer.

Profinet communication support: With the Profinet interface, KP32F panels can quickly and stably communicate with other devices, ensuring efficient data exchange in complex industrial networks.

Installation and maintenance

Installation: The KP32F panel is usually mounted with standard DIN rail, which is easy to install and can be embedded in the control panel or the front panel of the device.

Strong shell: The shell of the equipment is made of strong materials, which can effectively prevent the intrusion of dust, liquid and other external substances, and meet the industrial protection standards.

Easy maintenance: The equipment is simple in structure, easy to maintain, with long-term stability and high reliability, reducing maintenance costs. The long life of the keys on the keyboard reduces the frequency of replacement.

Application scenario

Industrial Automation Control: The KP32F panel is suitable for operation consoles in industrial automation control systems as an interface for users to interact with the automation system. Suitable for production line control, mechanical equipment operation, robot control and other fields.

Production equipment control: In applications that require control and setup through push-button operations, the KP32F panel helps operators quickly complete tasks such as adjusting equipment parameters, starting/stopping operations, and more.

Remote Monitoring and control: In scenarios where remote monitoring and control of equipment is required, KP32F can be used as a convenient input/output interface to enable quick operator response.

Console operation: Suitable for use as an input device for traditional mechanical consoles, especially in industrial environments where long running and frequent operations are required.

Technical parameter

Number of keys: 32 function keys, suitable for general control commands and setting operations.

Interface type: Profinet (PN) interface to ensure efficient data transfer and device connection to Siemens control systems.

Operating temperature range: Usually suitable for -20°C to +60°C working environment, to adapt to temperature fluctuations in industrial environments.

Enclosure protection class: The equipment has a good enclosure protection class (usually IP65), dust, water and corrosion resistance, suitable for harsh industrial sites.

Power requirements: 24V DC power supply to ensure stable operation of the device.

Advantages and characteristics

High reliability: Mechanical button design, with a long service life, suitable for use in high-frequency operating environments.

Easy operation: 32 physical keys allow for quick input and control for situations requiring precise operation.

Rugged and durable: Adapt to a variety of harsh industrial environments, with a high level of protection and anti-interference ability to ensure long-term stable operation of the equipment.

Industrial interface: Profinet interface is supported and compatible with Siemens automation systems to ensure fast and stable data transfer.

High integration: It can be seamlessly integrated with other Siemens automation equipment and systems (such as PLC, HMI, etc.) to simplify the setting and management of the operation interface.
