6AV2125-2JB23-0AX0 Siemens SIMATIC 9 Inch HMI KTP900F Mobile Panel

6AV2125-2JB23-0AX0 Details

Model and series

Model: 6AV2125-2JB23-0AX0

Series: SIMATIC HMI

Type: KTP900F Mobile Panel 9 Inch (9 inch touch screen mobile panel)

Function and use

Remote control and operation: As a mobile panel, the KTP900F allows operators to move freely within a factory or automation system and monitor and control equipment and production lines in real time. Suitable for production environments that require flexible operation.

Multi-function display: With a 9-inch touch screen, the KTP900F can display production data, equipment status, alarm information, and provide a rich operating interface to help operators efficiently manage the production process.

Man-machine interface: The HMI panel supports multiple control and monitoring functions and is suitable for device control, data acquisition, remote diagnosis, and monitoring scenarios.

Harsh environment: With IP65 protection grade, it is suitable for a variety of industrial environments and can effectively resist dust, moisture and other external factors.

Technical characteristics

9-inch touch screen: provides enough display area to support clear display of operation interface, parameter Settings, production data, etc., with high resolution and response speed.

Resolution: Generally 800x480 pixels, suitable for displaying clear graphics and text information, providing a more intuitive operation interface.

Resistive touch screen: Durable and sensitive for high frequency operating environments.

Profinet communication: Support Profinet protocol, can be seamlessly connected to Siemens PLC (such as S7-1200, S7-1500, etc.) and other automation control systems, to ensure rapid data transmission and remote operation efficiency.

Wireless communication options: Support wireless connectivity, can be connected with Wi-Fi and other devices, further improve the flexibility of remote operation.

High brightness display: The display provides clear readability even in bright light and is suitable for a variety of industrial environments.

Durable design: IP65 protection grade, adapt to dust, water vapor and vibration in harsh industrial environment, ensure long-term stable operation of equipment.

Compatibility

Compatible with Siemens PLC: Seamless connection with Siemens S7 series PLCS (such as S7-1200, S7-1500) and other automation equipment that supports the Profinet protocol ensures efficient data exchange.

Compatibility with other Siemens equipment: In addition to PLCS, it can also be compatible with drivers, sensors, actuators and other equipment to adapt to a variety of automation control applications.

Installation and maintenance

Easy installation: Support industrial panel installation, with flexible installation methods, suitable for control cabinets, equipment panels and other application scenarios.

Robust housing design: Electrical connection ports and operating interfaces are designed to meet the requirements of industrial environments, with high anti-interference and shock resistance.

Easy interface and operation: User-friendly graphical interface, easy operation and maintenance, reducing operator training costs.

Technical parameter

Display size: 9 inches

Resolution: 800 x 480 pixels

Touch screen type: Resistive touch screen, responsive

Communication protocol: Profinet, support efficient connection with Siemens PLC and other equipment

Protection grade: IP65, waterproof, dustproof, adapt to harsh environment

Operating temperature: Suitable for -20°C to +60°C working environment

Power requirements: 24V DC power supply

Wireless communication options: Support for Wi-Fi or other wireless protocols (depending on the model)

Advantages and characteristics

High quality display: Large 9-inch screen with high resolution and clarity, suitable for displaying complex control data, graphics and text information.

Flexible operation: As a mobile panel, the KTP900F supports remote control, allowing operators to flexibly move, monitor and operate multiple devices on the production site.

Industrial durability: IP65 protection grade, able to resist dust, moisture and other industrial environment interference, adapt to harsh working conditions.

Efficient connection: Support Profinet protocol, can be efficiently connected with Siemens PLC and other automation equipment, to ensure stable data transmission and equipment control.

Easy installation and operation: With a simple installation process and intuitive operation interface, operators can quickly get started and reduce maintenance costs.

Wireless communication capabilities: Support for wireless connectivity (depending on configuration) further enhances the flexibility and ease of operation of the device.

Application scenario

Automatic production line control: Suitable for automated production lines that require real-time monitoring and control, operators can remotely adjust production parameters by moving the panel to ensure the smooth progress of the production process.

Device monitoring and diagnosis: Used for device status monitoring, fault diagnosis, and remote maintenance to help technicians quickly locate and resolve problems.

Robot and Manipulator control: Suitable for the operation and monitoring of robots or robotic arms, capable of precise control from remote locations.

Energy Management: Can be used to display real-time energy consumption data to help businesses optimize energy use and improve efficiency.

Remote Equipment operation: With a wireless or wired connection, operators can operate equipment remotely, avoiding physical limitations and increasing productivity.
