6AV2125-2DB23-0AX0 Siemens SIMATIC 4 Inch HMI KTP400F Mobile Panel

6AV2125-2DB23-0AX0 Details

Model and series

Model: 6AV2125-2DB23-0AX0

Series: SIMATIC HMI

Type: KTP400F Mobile Panel 4 Inch (4 inch touch screen mobile panel)

Function and use

Flexible remote operation: As a mobile panel, the KTP400F allows operators to move flexibly on industrial sites, controlling and monitoring equipment at any time.

Multifunctional display: The 4-inch touch screen provides enough display space to display equipment status, production data, alarm information, and more to help operators respond quickly.

Equipment control and data monitoring: After connecting with Siemens PLC (such as S7-1200, S7-1500) and other equipment, equipment status monitoring, fault diagnosis, data collection and other operations can be carried out to ensure the stable operation of the production process.

High protection level: With IP65 protection level, it can be waterproof and dustproof in industrial environment to ensure long-term stable operation of equipment.

Technical characteristics

4-inch touch screen: Suitable for applications requiring a compact display interface, providing a clear display effect, easy to operate, suitable for smaller control interfaces and data presentations.

Resolution: 480 x 272 pixels, suitable for displaying clear graphics, text and operating interfaces.

Resistive touch screen: Durable and sensitive to handle frequent touch operations.

Profinet communication protocol: Support Profinet communication protocol, and realize efficient data transmission and control between Siemens PLC and other automation equipment.

Wireless communication options: Support for wireless connectivity enables operators to remotely control and monitor a larger area.

High brightness display: Even in strong ambient light, the display content is still legible and suitable for a variety of industrial environments.

Durable: IP65 protection grade, waterproof and dustproof design, adapt to changing industrial working environment.

Compatibility

Compatible with Siemens PLC: KTP400F can be seamlessly connected with Siemens S7-1200, S7-1500 series PLC and other automation equipment to ensure real-time data transmission and control.

Compatibility with other Siemens equipment: In addition to PLCS, the KTP400F also supports connectivity with other Siemens equipment such as drives, sensors, etc., for a variety of control and monitoring needs.

Installation and maintenance

Easy installation: Support a variety of industrial environment installation needs, such as wall-mounted, equipment panel installation, easy installation.

Anti-interference design: The equipment uses a strong shell, with anti-seismic, anti-interference ability to ensure stability in harsh environments.

Easy operation and maintenance: With a graphical touch screen interface, operators can easily monitor equipment, adjust parameters and collect data, reducing operator training time and cost.

Technical parameter

Display size: 4 inches

Resolution: 480 x 272 pixels

Touch screen type: resistive touch screen, high sensitivity

Communication protocol: Profinet, supports efficient connection with Siemens PLC and other automation equipment

Protection grade: IP65, waterproof and dustproof, suitable for industrial environment

Operating temperature: Suitable for -20°C to +60°C working environment

Power requirement: 24V DC

Wireless communication options: Support for Wi-Fi or other wireless connectivity options (depending on the model configuration)

Advantages and characteristics

Compact display: A 4-inch touch screen for space-constrained applications clearly displays device status, production data and alerts.

Flexible operation: With wireless or wired connections, operators can flexibly operate and monitor equipment on the plant site, increasing work efficiency.

High protection capacity: IP65 protection level ensures that the equipment can work stably in harsh environments such as dust and water vapor.

Efficient connection and communication: Efficient data transmission with automation equipment such as Siemens PLC through Profinet protocol to ensure real-time equipment monitoring and control.

Wireless connectivity options: Support for wireless communication, further enhancing the flexibility and remote operation of the device.

Strong durability: the equipment shell is strong, seismic, anti-interference, to ensure long-term stable operation in the industrial environment.

Application scenario

Automatic production line control: suitable for real-time monitoring and control of automated production lines, operators can adjust production parameters at different locations, monitoring equipment operation.

Device status monitoring: Used to monitor device running status, fault diagnosis, and alarm processing, helping maintenance personnel discover and solve problems in a timely manner.

Robot and robot arm control: It is suitable for the operation and control of robots and robot arms, and can remotely adjust the working state of the machine in different positions.

Logistics and warehouse management: suitable for warehousing and logistics management systems, operators can monitor the inventory situation and operate at any time on site.

Energy Management and Monitoring: Real-time energy consumption data can be displayed to help companies manage energy, optimize production processes and reduce costs.
