6AV2123-2MA03-0AX0 Siemens KTP1200 Basic 12 Inch Touch Screen HMI

6AV2123-2MA03-0AX0 Details

Model and series

Model: 6AV2123-2MA03-0AX0

Series: SIMATIC HMI

Type: KTP1200 Basic 12 Inch Touch Screen HMI (12 inch touch Screen HMI)

Function and use

Advanced user interface: The KTP1200 panel increases operator productivity by providing a 12-inch touch display for applications that require large amounts of information or complex graphical interfaces to display multiple data items or graphics at the same time.

Monitoring and control: This HMI panel is connected with Siemens PLC, driver and other automation equipment, and can display real-time machine status, production data, trend chart, alarm information, etc., and support touch screen input command for operation control.

Multi-language support: Support multi-language interface, can meet the needs of global users, convenient international applications.

Diagnostic and alarm functions: Built-in diagnostic and alarm functions help operators identify equipment failures and system warnings, and take timely action to prevent line downtime or equipment damage.

Technical characteristics

12-inch touch screen: Equipped with a large 12-inch color touch display with high resolution, suitable for applications that need to display more information. High resolution can display clear charts, trends, status information and more.

Resolution: Typically 1280 x 800 pixels, suitable for the display of complex graphics, data and text content, ensuring that the operator can clearly see the production data and control interface.

Sensitive touch operation: Capacitive touch screen, support multi-touch, operation response speed, accurate touch, intuitive operation.

Profinet Connectivity: Supports high-speed data exchange with PLCS and other automated control devices via the Profinet protocol to ensure real-time monitoring and control operations.

Strong industrial design: with a high level of protection, can adapt to the working environment of the industrial site, such as high temperature, dust, moisture, etc.

Compatibility

Compatible with Siemens PLC: The KTP1200 HMI panel is compatible with Siemens PLC (such as S7-1200, S7-1500, etc.), supports Profinet connection, and can achieve fast data transmission and real-time control.

Support for multiple device connections: In addition to PLC compatibility, the KTP1200 panel also supports connection with other automation devices such as drivers, sensors, robots, etc., for a variety of industrial automation control applications.

Installation and maintenance

Installation method: Support panel installation, wall installation or DIN rail installation, can flexibly adapt to various installation requirements, especially suitable for large space or need to display a lot of information equipment and production lines.

Industrial grade design: The KTP1200 panel has a strong housing, usually IP65 protection class, which can resist dust and moisture in industrial sites, ensuring long-term stable operation of the equipment.

Easy operation and maintenance: The HMI panel interface is easy to operate and configure, enabling quick system commissioning and troubleshooting to help reduce maintenance time.

Technical parameter

Display size: 12 inches for industrial applications that require a large display area.

Resolution: 1280 x 800 pixels, the display effect is clear, suitable for displaying multiple data items or complex control interfaces.

Touch screen type: Capacitive touch screen, support multi-touch, responsive operation.

Interface type: Profinet, Ethernet and other industrial communication interfaces, suitable for Siemens and other automation equipment connection.

Operating temperature range: suitable for -20°C to +60°C working environment, can work stably in various industrial environments.

Protection grade: IP65, dustproof, waterproof, suitable for harsh industrial environment.

Power requirements: 24V DC power supply, in line with industry standard voltage requirements.

Advantages and characteristics

Large display size: The large 12-inch screen is suitable for displaying a large amount of production data, control parameters, graphics and trend charts, providing increased visualization and operating comfort.

High resolution display: The 1280 x 800 resolution makes the display clearer and can handle complex charts, data, and high-resolution graphics to improve the operator experience.

Multi-touch support: Capacitive touch screens support multi-touch, allowing operators to quickly enter commands, select menus, or control devices with intuitive gestures.

Powerful communication function: Support Profinet communication protocol, can be seamlessly connected with Siemens PLC, drivers and other automation equipment to ensure real-time data exchange and control operations.

Rugged: With IP65 protection grade, adapt to the harsh environment such as high temperature, moisture and dust in the industrial site, to ensure the long-term reliable operation of the equipment.

Flexible installation: Support panel, wall and DIN rail installation, can flexibly adapt to different installation requirements, suitable for a variety of industrial application scenarios.

Application scenario

Complex production line control: Suitable for large or complex production lines, which need to display a large number of equipment data, control parameters and real-time status information.

Energy Management and monitoring: In the energy monitoring system, the KTP1200 HMI can display real-time energy consumption data, control Settings and alarm information to help optimize energy utilization.

Mechanical equipment control: connected with the machine control system to provide a clear operation interface for equipment status monitoring, data display and fault diagnosis.

Automated control system: Suitable for automated control tasks, especially in cases where large amounts of data and graphics need to be displayed, providing the operator with an intuitive operating interface.

Robot and automation equipment monitoring: Integration with industrial robots, automation equipment and systems to provide monitoring, control and data exchange functions.
