6AV2123-2GB03-0AX0 Siemens KTP700 Basic 7 Inch Touch Screen HMI

6AV2123-2GB03-0AX0 Details

Model and series

Model: 6AV2123-2GB03-0AX0

Series: SIMATIC HMI

Type: KTP700 Basic 7 Inch Touch Screen HMI (7 inch touch Screen HMI)

Function and use

Operation interface: This HMI panel provides an intuitive, touch-enabled interface for operating, monitoring, and controlling industrial automation equipment. It can be connected to Siemens PLC, drive and other control equipment, display control data, machine status and production parameters.

Data display and control: The KTP700 panel can display real-time data, charts, alarm information, production progress, etc., and allow the operator to enter commands, adjust Settings, start/stop equipment through the touch screen.

Diagnosis and alarm function: Built-in alarm function can display fault and warning information to help operators intervene in time to ensure the smooth progress of the production process.

Multi-language support: Support multi-language interface, interface can be switched according to user needs, suitable for different countries and regions.

Technical characteristics

7-inch touch screen: Equipped with a 7-inch color touch screen, the panel provides a clear and intuitive display, suitable for displaying device status, parameters, trends and other information.

Resolution: The panel has a high resolution display effect, usually 800x480 pixels, ensuring that the display content is clearly visible.

Operating system: Siemens own operating system, support graphical interface, with better response speed and user experience.

High reliability: Designed with a strong industrial grade housing, strong anti-interference, able to work stably in harsh industrial environments.

Flexible connection method: Support a variety of communication protocols, including Profinet, Ethernet, etc., and PLC and other automation system equipment for seamless connection.

Low power design: The energy-saving design reduces the system power consumption and extends the service life of the equipment.

Compatibility

Compatible with Siemens PLC: The HMI panel is compatible with Siemens S7-1200, S7-1500 series PLC and other control devices, and communicates via standard protocols such as Profinet or Ethernet.

Support for a wide range of industrial equipment: In addition to being compatible with Siemens PLC, it can also be connected to other automation systems, drivers, sensors and other equipment for a wide range of industrial applications.

Installation and maintenance

Installation method: The KTP700 Basic HMI panel supports panel installation, wall installation or DIN rail installation, and the installation method is flexible to adapt to the needs of different field environments.

Industrial design: The panel has a high protection level (usually IP65), dustproof, waterproof, to adapt to the harsh environment of the industrial site.

Simple operation: Provides a simple graphical operation interface, easy to set up and operate, reducing operator training costs.

Easy maintenance: Built-in fault diagnosis function allows operators to view equipment status and alarm information in real time to quickly identify and troubleshoot faults.

Technical parameter

Display size: 7-inch touch screen, suitable for monitoring and operation of small and medium-sized devices.

Resolution: 800 x 480 pixels, ensuring clear display of various information.

Interface type: Support Profinet, Ethernet, RS232 and other common communication interfaces, easy to integrate with other automation equipment.

Operating temperature range: Usually suitable for -20°C to +60°C working environment, to adapt to temperature fluctuations in industrial sites.

Shell protection grade: IP65, with waterproof, dustproof ability, suitable for various industrial environments.

Power requirements: 24V DC power supply, stable operation.

Touch screen type: resistive touch screen or capacitive touch screen (depending on the model) to adapt to different operation requirements.

Advantages and characteristics

Intuitive touch operation: A 7-inch color touch screen provides a clear and intuitive user interface that simplifies operator interaction.

Multifunctional display: can display real-time data, trend charts, alarm information, etc., to help operators quickly understand the equipment status.

High reliability: With a high level of protection and anti-interference ability, adapt to the harsh conditions in the industrial environment to ensure long-term stable operation.

Flexible connection: Support a variety of communication interfaces such as Profinet and Ethernet, adapt to the needs of different automation control systems, and easily integrate with PLC and other devices.

Low-power design: reduces power consumption, prolongs equipment service life, and reduces operating costs.

Easy integration and maintenance: Easy to use interface, fast configuration and commissioning, with fault diagnosis to reduce maintenance time.

Application scenario

Automatic production line: used for monitoring and operation of the production line, display production data, equipment status, alarm information, etc., to help operators carry out real-time control.

Mechanical equipment control: In the mechanical control system, the KTP700 panel acts as the control interface to provide equipment status feedback and control command input.

Energy management system: Used for energy consumption monitoring and management to help enterprises optimize resource use and reduce energy consumption.

Industrial robot control: It can be connected with the industrial robot control system for parameter setting, operation control and diagnosis.

Facility Management: Applicable to the monitoring and control of equipment in facilities, such as HVAC systems, water treatment equipment, etc.
