6AV2123-2DB03-0AX0 Siemens KTP 400 Basic 4 Inch Touch Screen HMI

6AV2123-2DB03-0AX0 Details

Model and series

Model: 6AV2123-2DB03-0AX0

Series: SIMATIC HMI

Type: KTP400 Basic 4 Inch Touch Screen HMI (4 inch Touch Screen HMI)

Function and use

Basic display and control: KTP400 Basic is mainly suitable for simple to medium complexity industrial automation tasks, can display basic production data, equipment status, alarm information, and support the operator for simple touch control.

Equipment Monitoring and alarm: This HMI device can monitor the status of the machine or production equipment in real time, providing quick alarm information, equipment status updates and necessary operating commands via the touch screen.

Compact design: Thanks to its compact 4-inch display, the KTP400 is ideal for space-limited applications such as small control panels, device panels, compact machines, etc.

Multi-language support: supports multiple languages, and can switch the display language according to requirements, which is convenient for different regions and language environments.

Technical characteristics

4-inch touch screen: Suitable for use in space-constrained situations, it can display a simple control interface and basic device information.

Resolution: Usually 480x272 pixels, suitable for displaying simple text, symbols and basic graphics, ensuring that the operator can clearly see the device status and control interface.

Touch screen Type: Resistive touch screen provides high reliability and durability in high frequency operation and harsh industrial environments.

Profinet connection: Support Profinet communication protocol, can be with Siemens PLC (such as S7-1200, S7-1500, etc.) and other automation equipment to achieve efficient connection and data exchange.

Protection grade: IP65 protection grade, dustproof, waterproof, suitable for various industrial environments, to ensure long-term stable operation of equipment.

Compatibility

Compatible with Siemens PLC: Compatible with Siemens S7-1200, S7-1500 and other PLCS, capable of efficient connection and data exchange through Profinet, suitable for various automation control systems.

Connection with other automation equipment: In addition to PLC, it can also be connected with drivers, sensors, actuators and other equipment, suitable for various industrial control applications.

Installation and maintenance

Installation method: Support panel installation, suitable for installation in standard control panel or machine panel, suitable for equipment and production lines with limited space.

Rugged design: Strong housing, anti-seismic and anti-interference, suitable for various industrial environments, can operate normally in high temperature, moisture or dust environment.

Easy operation and maintenance: The interface design is simple and intuitive, easy for operators to learn and use, reducing operator training and maintenance costs.

Technical parameter

Display size: 4 inches for space-constrained applications.

Resolution: 480 x 272 pixels, suitable for simple graphics and text display.

Touch screen type: Resistive touch screen for high frequency operation in industrial environments.

Interface type: Profinet to ensure efficient connection with Siemens PLC and other equipment.

Operating temperature range: Suitable for -20°C to +60°C working environment, to ensure stable operation of equipment in a variety of industrial environments.

Protection grade: IP65, dustproof, waterproof, suitable for harsh industrial environment.

Power requirements: 24V DC power supply, in line with industry standard voltage requirements.

Advantages and characteristics

Compact size: 4-inch display for space-saving applications such as small devices and compact control panels.

High resolution display: The 480 x 272 pixel resolution clearly displays basic text, symbols, and small graphics, ensuring that the operator can easily read device status and parameters.

Touch operation: Resistive touch screen is responsive, suitable for high frequency operation, the operation interface is simple, intuitive, easy to use.

Rugged: IP65 protection grade, can resist dust, moisture and other industrial environment, adapt to a variety of harsh working conditions.

Cost-effective: As a basic HMI, the KTP400 offers an excellent balance between function and cost, making it suitable for industrial applications where the control interface is not as demanding.

Reliable connection: Support Profinet communication protocol, and can quickly and stably exchange data and control operations with Siemens PLC and other automation equipment.

Application scenario

Small equipment control: suitable for equipment requiring a simple control interface, such as small conveyor belts, packaging equipment, robots, etc.

Automatic production line: suitable for the control of small production lines or monitoring equipment, capable of displaying basic operating parameters, equipment status and alarm information.

Simple monitoring system: used for machine equipment status monitoring, operation diagnosis and basic alarm function.

Energy Management: Suitable for energy monitoring systems, display power consumption data and provide real-time alarms.

Instrument control: can be used in all kinds of instruments and measuring equipment, as a display and operation interface.
